Cooling Chambers ICH-Compliant Light Source and Light dose Control
Cooling Chambers ICH-Compliant Light Source and Light dose Control
Cooling Chambers ICH-Compliant Light Source and Light dose Control
Cooling Chambers ICH-Compliant Light Source and Light dose Control
Related products
  • Product features
  • Technical parameter
  • Options and accessories
  • - Imported Honeywell PT1000 temperature sensor for more precise temperature control

    - Fixed value and program control

    - With automatic start, automatic stop, timed operation, clock display function

    - Ambient temperature detection function

    -Door switch monitoring function

    - Five-level automatic defrosting function, and manual defrosting function

    - Logging function (touch screen implementation)

    - Fault monitoring, alarm, recording function (touch screen implementation)

    -Level 4 password function: login password, operator password, administrator password, senior administrator password (touch screen implementation)

    - Three power-off mode selection functions: power-off recovery, stop or restart (touch screen implementation)

    - Curve display function (touch screen implementation)

    -GPRS SMS alarm function (touch screen implementation)

    - Real-time data and historical data printing (touch screen implementation)

    - Touch screen data storage function; an ambient temperature detection function (touch screen implementation)

    - Optional computer monitoring software for connecting 6 devices with temperature calibration

    - Water level monitoring and automatic water replenishment function (controlled humidity type)

    Effective volume LCD series Touch screen series
    150L LBI-150 LBI-150T
    250L LBI-250 LB1-250T
    450L LBI-450 LB1-450T
    750L LBI-750 LB1-750T
    1100L LBI-1100 LB11100T
    Temperature range 0℃~70℃ 0℃~70℃
    Temperature display accuracy 0.1℃ 0.1℃
    Temperature control method Fuzzy intelligence P.l.D Fuzzy intelligence P.l.D
    Illumination range 10~10000Lux 10~10000Lux
    Ultraviolet irradiance 80~100μw/cm² 80~100μw/cm²
    Log, audit trail No Have
    Curve display function No Have
    Real-time data, historical data monitoring and printing functions No Have
    Level 4 password function No Have
    Data storage function No Have
    Fault monitoring, alarm, recording No Have
    Defrosting method Level 5 automatic defrost and manual defrost
    Frost-free area Frost-free operation above 20 degrees
    Temperature Sensor Import Honeywell PT1000
    Three power-down mode selection functions Power failure recovery, stop or restart
    Test hole Left and right double test holes
    Insulation Materials Polyurethane foam



    Volume (liter) 150 250 450 750 1100
    Liner size(W*D*H)mm 540*400*700 640*440*890 750*500*1200 1250*500*1200 1250*735**1200
    Dimensions(W*D*H)mm 700*830*1300 800*870*1470 910*930*1785 1430*960*1800 1430*1195*1800
    Temperature uniformity(37℃时) ±0.5℃ ±0.5℃ ±0.5℃ ±0.8℃ ±0.8℃
    Cooling power 400W 500W 600W 800W 1000W
    Heating power 750W 750W 1500W 2200W 2500W
    Shelf Three floors Three floors Four floors Four floors Four floors
    product weight About 96kg About 117kg About 186kg About 216kg About 256kg



    -The test technical data is only applicable to the test results under the no-load condition of the equipment and the ambient temperature is 25 degrees!


    -The appearance and parameters of the product are subject to change without notice. The appearance of the product may vary due to photography and printing. Please understand!

    -GPRS mobile phone SMS alarm
    -Computer monitoring software
    - Visible/UV lamp total illumination control system
